F4U Corsair 'Blue/Yellow' 71in Wingspan ARF
Buy On Hobbyplastic.co.uk
Find Your Local MacGregor StockistAdditional Images:
Click On Images to Enlarge
Overview
The Vought F4U Corsair is an American fighter aircraft that saw service primarily in World War II and the Korean War . Designed and initially manufactured by Chance Vought, the Corsair was soon in great demand The Corsair was designed and principally operated as a carrier-based aircraft , and entered service in large numbers with the U.S. Navy and Marines in World War II. It quickly became one of the most capable carrier-based fighter-bombers of the war. Some Japanese pilots regarded it as the most formidable American fighter and U.S. naval aviators achieved an 11:1 kill ratio.
VQ Model introduces the F4U Corsair in the most popular size (120 size). You have a lot of power options, from nitro 2-stroke 120, nitro 4-stroke 125-150 (Saito FA-125A/FA-150B), gas 21-25 cc, electric motor and even fit with Saito FG-33R3 Radial engine. With lots of scale details like the WWII US Navy Pilot, Rocket, Subtank... make your F4U Corsair the most scale warbird on your flying field.
Specifications:
| Wingspan: | 1810mm (71in) |
|---|---|
| Fuselage Length: | 1390mm (54.7in) |
| Weight: | 6.3 - 6.7kg |
| Nitro Engine required (Not Supplied): | 120 (2 stroke) or 125-150 (4 stroke) |
| Gas Engine required (Not Supplied): | 20-26cc (2 stroke) or 21-30cc (4 stroke) | Radial Engine - Saito FG-33R3 or FA-200R3 |
| Electric Motor (Not Supplied): | TBC |
| Battery (Not Supplied): | Lipo 6S 6000 mAh |
| Propeller (Not Supplied): | 17 x 6 - 19 x 6 |
| Radio required (Not Supplied): | 9 channels with 12 servos - Standard servo (2 x Aileron, 2 x Elevator, 1 x Rudder) | Mini Servo (4 x Flaps, 2 x Main Gear Door, 1 x Throttle) |
Features:
- All balsa and lite-ply construction
- Fibreglass cowling
- Control surfaces pre-hinged and installed
- Fully covered in weathered detail
- Scale Navy Pilot
- 3D printed Rocket
- All main gear door operation
Includes:
- Assembly instructions - [ Download ]
- Gear assembly
- Wheels
- Engine mounts
- Fuel tank
- Fibreglass cowling
- Aluminium wing joiner
- Decals and all hardware
- Optional:95 Degree Aluminium Rotating Electric Retracts with Scale struts (VQARE34)
Does not include: radio, motor, glue, and silicon fuel line
Recommended Hardware (Not Supplied):
- Servos: 5 x MG5510DS 9.98Kg.cm/0.12s Standard Size Digital Servo and 7 x MG1703DS 3.3Kg.cm/0.10s Mini Digital Servo
- Engine: DLE20 2-Stroke Petrol Engine | Saito FA-125A 4-Stroke Glow/Nitro Engine | Saito FG-21 4-Stroke Petrol Engine
- Radial Engine: Saito FA-200R3 4-Stroke Glow/Nitro Engine | Saito FG-33R3 4-Stroke Petrol Engine
Order Code: VQA170BY
Manufactured By: VQ Models
Manuals/Downloads
